Enerpac HSL Series – Hydraulic Strand Jacks
For Sale or Rent
Kitchen’s Crane & Equipment partners with Enerpac to offer Strand Jacks from 17-955 tons.
The strand jack lifting technique originates from the concrete post tensioning principle. A strand jack can be considered a linear winch. In a strand jack, a bundle of steel cables or strands are guided through a hydraulic cylinder; above and below the cylinder are anchor systems with wedges that grip the strand bundle. By stroking the cylinder in and out while the grips are engaged in the anchors, a lifting or lowering movement is achieved.
HSL1507, 17 Ton, Hydraulic Strand Jack
Maximum Operating Pressure: 5,000 psi (350 bar)
Capacity: 17 imperial tons (15 metric tons)
Strand Diameter: 0.71 in (18 mm)
Number of Strands: 1
Stroke: 9.8 in (250 mm)
Weight: 220 lbs (100 kg)
HSL4507, 51 Ton, Hydraulic Strand Jack
Maximum Operating Pressure: 5,000 psi (350 bar)
Capacity: 51 imperial tons (45 metric tons)
Strand Diameter: 0.71 in (18 mm)
Number of Strands: 3
Stroke: 18.9 in (480 mm)
Weight: 1102 lbs (500 kg)
HSL7006, 79 Ton, Hydraulic Strand Jack
Maximum Operating Pressure: 5,000 psi (350 bar)
Capacity: 79 imperial tons (70 metric tons)
Strand Diameter: 0.62 in (15,7 mm)
Number of Strands: 7
Stroke: 18.9 in (480 mm)
Weight: 1411 lbs (640 kg)
HSL10007, 112 Ton, Hydraulic Strand Jack
Maximum Operating Pressure: 5,000 psi (350 bar)
Capacity 112 imperial tons (100 metric tons)
Strand Diameter: 0.71 in (18 mm)
Number of Strands: 7
Stroke: 18.9 in (480 mm)
Weight: 1874 lbs (850 kg)
HSL20006, 225 Ton, Hydraulic Strand Jack
Maximum Operating Pressure: 5,000 psi (350 bar)
Capacity: 225 imperial tons (200 metric tons)
Strand Diameter: 0.62 in (15,7 mm)
Number of Strands: 19
Stroke: 18.9 in (480 mm)
Weight: 2860 lbs (1300 kg)
HSL50006, 562 Ton, Hydraulic Strand Jack
Maximum Operating Pressure: 5,000 psi (350 bar)
Capacity: 562 imperial tons (500 metric tons)
Strand Diameter: 0.62 in (15,7 mm)
Number of Strands: 48
Stroke: 18.9 in (480 mm)
Weight: 6930 lbs (3150 kg)
HSL85007, 955 Ton, Hydraulic Strand Jack
Maximum Operating Pressure: 5,000 psi (350 bar)
Capacity: 955 imperial tons (850 metric tons)
Strand Diameter: 0.71 in (18 mm)
Number of Strands: 55
Stroke: 18.9 in (480 mm)
Weight: 1023 lbs (5000 kg)
